Pixel Pitch of indoor led display: 1.563mm

Module size: 200x150mm

Pixel Configuration: 1R1G1B

LED type: SMD1010

Resolution: 409600 dots per square meter

Cabinet type: die casting aluminum cabinet

Cabinet Size: 400x300mm

Cabinet weight: 30Kg/㎡

Maintenance type: Back or front

Protective grade: IP30

Brightness: 600~800 nits/㎡.

Scanning frequency: 1/48

Best view distance: >=1.563 meters

Power consumption: Average 400W W/㎡

Input Voltage: AC220V/50Hz or AC110V/60Hz.

Viewing Angle: 160°/160° (H/V).

Refresh frequency:1920Hz, 3840Hz.

Earth Leakage Current: ≤ 3mA

Dot Defects Rate: ≤ 0.0001

MBTF: 50,000 hours.

Lift span: 100,000 hours.

Operating Temp.& RH: ﹣20℃～65℃ / 20%～90%RH

Strorage Temp. & RH:  ﹣40℃～80℃ / 20%～90%RH

Adopted Control System: PCTV Board + DVI Board + Control Board + Network cable Transmission

Video Signal: RF, S-Video, RGB, RGBHV, YUV, YC, COMPOSITION- YPbPr, PAL/NTSC,HDMI, VGA, HD_SDI etc

Gray grade: 256 degree.
