Product lnformation

Optional model of  indoor bus led screen led dispaly: P2,P3,P4,P5,P6,P7.62

Module size: 192x192mm, 256x128mm, 320x160mm, 244x122mm

Pixel Configuration: 1R1G1B

Resolution: Based on model and cabinet size

Cabinet type: Steel or aluminum

Cabinet Size: can be customized

Cabinet weight: based on cabinet type and cabinet size

Maintenance type: Back

Protective grade: IP50

Brightness: 800~1500 nits/㎡.

Scanning frequency: 1/16, 1/32

Best view distance: >=2 meters

Power consumption: Average 200W~300 W/㎡

Input Voltage: AC220V/50Hz or AC110V/60Hz.

Viewing Angle: 160°/160° (H/V).

Refresh frequency: 1920Hz, 3840Hz.

Earth Leakage Current: ≤ 3mA

Dot Defects Rate: ≤ 0.0001

MBTF: 10,000 hours.

Lift span: 100,000 hours.

Operating Temp.& RH: ﹣20℃～60℃ / 20%～90%RH

Strorage Temp. & RH:  ﹣40℃～80℃ / 20%～90%RH

Adopted Control System: PCTV Board + DVI Board + Control Board + Network cable Transmission

Video Signal: RF, S-Video, RGB, RGBHV, YUV, YC, COMPOSITION- YPbPr, PAL/NTSC,HDMI, VGA, HD_SDI etc

Gray grade: 256 degree.
