Product lnformation

1. Optional model of indoor film transparent led screen: P4-8, P5-10, P6, P6.5, P8, P10, P16, P20
2. Module size: 480X256mm or 480X320mm, or 480X192mm
3. Pixel Configuration: 1R1G1B
4. LED type: SMD 3 in 1
5. Cabinet type: Steel cabinet and die casting aluminum cabinet.
6. Cabinet Size: Do not need cabinet
7. weight: 3.5Kg/㎡
8. Maintenance type: Back
9. Protective grade: P65
10. Brightness: 1500~5000 nits/㎡.
11. Scanning frequency: 1/2, 1/4, 1/8
12. Best view distance: 4m ~ 500m.
13. Power consumption: 200W ~ 800W/㎡ based on different model.
14. Input Voltage: AC220V/50Hz or AC110V/60Hz.
15. Viewing Angle: 160°/160° (H/V).
16. Refresh frequency: 1920Hz, 3840Hz.
17. Earth Leakage Current: ≤ 3mA
18. Dot Defects Rate: ≤ 0.0001
19. MBTF: 6,500 hours.
20. Lift span: 100,000 hours.
21. Operating Temp.& RH: ﹣20℃～65℃ / 20%～90%RH
22. Strorage Temp. & RH:  ﹣40℃～85℃ / 10%～95%RH
23. Adopted Control System: PCTV Board + DVI Board + Control Board + Network cable Transmission
24. Video Signal: RF, S-Video, RGB, RGBHV, YUV, YC, COMPOSITION- YPbPr, PAL/NTSC,HDMI, VGA, HD_SDI etc
25. Gray grade: 256 degree.
26. Max. color of display: 65536x65536x65536.
