Product lnformation

Pixel Pitch of P16 outdoor led screen: 16mm

Module size: 256x128mm or 256x256mm

Pixel Configuration: 1R1G1B

Resolution: 3906 dots per square meter

LED type: SMD3535

Cabinet type: Steel cabinet

Cabinet Size: it can be customized for steel cabinet;

Cabinet weight: 40Kg/㎡ for steel cabinet;

Maintenance type: Back or front

Protective grade: IP65 in front and IP54/55 on back

Brightness: 5000~6500 nits/㎡.

Scanning frequency: 1/2

Best view distance: >=16 meters

Power consumption: Average 300W W/㎡

Input Voltage: AC220V/50Hz or AC110V/60Hz.

Viewing Angle: 160°/160° (H/V).

Refresh frequency: 720Hz, 1920Hz, 3840Hz.

Earth Leakage Current: ≤ 3mA

Dot Defects Rate: ≤ 0.0001

MBTF: 50,000 hours.

Lift span: 100,000 hours.

Operating Temp.& RH: ﹣20℃～65℃ / 20%～90%RH

Strorage Temp. & RH:  ﹣40℃～80℃ / 20%～90%RH

Adopted Control System: PCTV Board + DVI Board + Control Board + Network cable Transmission

Video Signal: RF, S-Video, RGB, RGBHV, YUV, YC, COMPOSITION- YPbPr, PAL/NTSC,HDMI, VGA, HD_SDI etc

Gray grade: 256 degree.
